Description
-
Full DC Inverter: Achieves up to 17 SEER2 for meaningful energy savings and lower utility costs.
-
Twin Rotary DC Inverter: Delivers smoother, low-friction operation, stable rotation, reduced vibration, and significantly quieter performance with no refrigerant leakage during compression.
-
Flexible Installation: Supports multiple configurations, including roof-curb mounting with rear or bottom duct connections, slab-on-grade installation, standard bottom return/supply, and optional side-discharge airflow.
-
Copper Piping: Constructed with high-quality copper tubes for stronger durability, better heat transfer, superior pressure resistance, and longer system life compared to aluminum alternatives.
-
Service-Friendly Design: Built for easy access and straightforward maintenance to minimize service time and improve overall system reliability.
-
A2L Safe: Uses R-32, a high-performance refrigerant with superior heat-transfer efficiency and a lower global-warming potential compared to traditional refrigerants, resulting in improved cooling capacity and reduced environmental impact.
-
BlueFin Coil Protection: Features BlueFin hydrophilic coating on outdoor coils to enhance corrosion resistance, improve heat-exchange efficiency, and extend coil life in harsh or coastal environments.
| TECHNICAL SPECIFICATIONS | |
| Ton | 3 |
| Power Supply | 208~230V/1Ph/60Hz |
| SEER | 18.5 |
| Heat Pump | Yes |
| Refrigerant Gas | R32 |
| Compressor Brand | GMCC |
| Compressor Type | Twin Rotary |
| SKU | EPKH03625HA-18 |
| DIMENSIONS | WEIGHT | ||||||||||||||||||||||||||||||||||||||||||
| UNIT | |||||||||||||||||||||||||||||||||||||||||||
| Dimension (W*H*D) | 51×31-1/4×43-1/4 in
1295x795x1100 mm |
Net | 404.5 lb
183.5 kg |
||||||||||||||||||||||||||||||||||||||||
| Packing (W*H*D) | 51-1/8×33-1/2×33-3/4 in
1300x856x1105 mm |
Shipping | 411.5 lb
186.6 kg |
||||||||||||||||||||||||||||||||||||||||
***You can make your orders per model and optimize the loading capacities for the container.
| WHOLESALER | |
| LOADING x CONTAINER | 40HQ Floor Loaded |
| Sets | 54 Pcs |
|
Although we receive less than 0.02% defects claims on our wide range of products, it is better to be safe than sorry! Take advantage of our Limited Warranty by registering your product for warranty as soon as it is installed by a licensed HVAC Technician.
If you are looking for technical support, you can contact us via email at (customerservice@everwellparts.com) or call our toll-free support line +1(800)226-9550 from Monday through Friday, 9:00 am to 5:00 pm ETA. |
|
|
|
|
Disclaimer: Specifications are subject to change without notice. Everwell Parts, Inc. is not liable for errors or changes from the manufacturer. Verify all details before installation.
